Robust Multi-Pole Meter Isolation with Garo
Garo GP4100M – 4 Pole 100A Meter Supply Isolator
The Garo GP4100M 4 Pole 100A Meter Supply Isolator delivers safe and dependable circuit disconnection for meter installations. Designed with a durable enclosure and modular DIN rail mounting, it provides reliable protection in both residential and commercial environments.
Built to IEC/EN 60947-3 standards, the GP4100M offers professional-grade performance with IP40 protection and a mechanical red/green contact position indicator for enhanced safety. Its 4-pole configuration makes it ideal for three-phase and neutral supply installations.
Key Features – Garo GP4100M
- 4 Pole meter supply isolator rated at 100A
- Complies with IEC/EN 60947-3 standards
- Compact modular DIN rail design
- Clear mechanical red/green contact position indicator
- Top or bottom supply connections for installation flexibility
- IP40 enclosure for dependable protection
Technical Overview – Garo GP4100M
- Rated current (In): 100A
- Rated operational voltage (Ue): 230/400V AC
- Rated insulation voltage (Ui): 1000V
- Rated impulse withstand voltage (Uimp): 4kV
- Utilisation category: AC-22A
- Short-time withstand current: 16kA
- Poles: 4
- Frequency: 50/60Hz
- Device height: 68mm (DIN rail EN60715)
- Device width: 72mm (4 x 18mm modules)
- Terminal capacity: 1–50mm²
- Terminal screw: M6 (Pozidrive PZ2)
- Terminal torque: max 3Nm
- Operating temperature: -25°C to +55°C
- Storage temperature: -40°C to +70°C
✅ Why Choose This Product?
The Garo GP4100M is the professional choice for reliable multi-pole meter isolation. Its 100A rating, 4-pole flexibility, and durable enclosure make it perfectly suited for modern three-phase installations where safety and compliance are critical.
️ Guarantee & Compliance
This product complies with the Low Voltage Directive (2014/35/EU) and RoHS Directive (2011/65/EU). Built to IEC/EN 60947-3 standards, it ensures safe and reliable performance in demanding installations.
