Description
Rugged Metal IP65 Empty Enclosure for Compact Distribution
Durable Power Distribution with Garo GM5-5D
The Garo GM5-5D 5 Module Metal IP65 Enclosure delivers secure, compact power distribution with IP65 sealing and a robust steel body. Fully compliant with EN 61439-3 and BS 7671 (18th Edition), it’s built for dependable performance in demanding environments.
✨ Key Features – Garo GM5-5D 5 Module Metal IP65 Enclosure
- 5-module empty metal enclosure
- Rated current: 100A | Rated voltage: 230V AC | 50/60 Hz
- Rated conditional short-circuit (Icc): 16kA rms at 250V
- IP65 sealing for dust and water resistance
- Durable steel construction with corrosion-resistant finish
- Terminals up to 35 mm² conductors
- Operating temperature: −25 °C to +55 °C
- 18th Edition ready – compliant with BS 7671
Technical Overview – Garo GM5-5D
- Protection class: IP65
- Rated current: 100A | Max backup protection: 100A
- Voltage & frequency: 230V AC, 50/60 Hz
- Short-circuit withstand: 16kA rms at 250V
- Total number of ways: 5 (0 free)
- Dimensions (H×W×D): 240 × 165 × 98 mm
- Ambient: −25 °C…+55 °C | Storage: −35 °C…+55 °C
- Standards & directives: EN 61439-3, LVD 2014/35/EU, RoHS 2011/65/EU
✅ Why Choose This Product?
The GM5-5D combines a tough metal enclosure with IP65 sealing to protect critical circuits against dust and water. With 100A rating, 16kA Icc, and full 18th Edition compliance, it’s a reliable, trade-ready choice for domestic and light commercial work.
️ Guarantee & Compliance
This enclosure conforms to EN 61439-3 and is compliant with BS 7671 (18th Edition). It also meets LVD 2014/35/EU and RoHS 2011/65/EU requirements, supporting safe and sustainable installations. Specs verified from the official Garo documentation.
