24 Way Double Row RCBO Consumer Unit – No SPD, FuseBox F3
FuseBox F3024M
The FuseBox F3024M 24 Way RCBO Board is a 24-way double bank consumer unit, designed for larger installations needing high circuit capacity. It includes a 100A double pole main switch and does not come with a surge protection device (SPD). That means all ways are free to use with RCBOs and modular devices.
This unit belongs to the latest FuseBox F3 range and features metal construction, an improved DIN rail tail clamp, and a stronger grommet strip. It meets all current safety requirements under BS7671 18th Edition.
Key Features – FuseBox F3024M 24 Way RCBO Board
- 24 usable ways – arranged in a double row (12+12 layout)
- Supplied with 100A DP main isolator (double pole)
- All-metal body with RAL 9001 powder-coated finish
- Factory-installed DIN rail tail clamp for faster wiring
- Upgraded grommet strip for safer cable protection
- Full compliance with 18th Edition Wiring Regs (BS7671)
Technical Overview – F3 Design
- Voltage: 230V AC | Frequency: 50/60Hz
- DIN rail width: 35mm
- Knockouts: Rear, top, bottom, and sides (20–40mm)
- Fully labelled neutral and earth bars
- Includes hinged front cover for easy access
What’s New in the FuseBox F3 Range?
- Tail Clamp – Pre-mounted securely on the DIN rail
- Grommet Strip – Reinforced for long-term use
Always Use Correct Torque Tools
Install all terminals using a calibrated torque screwdriver. The FuseBox manual shows the correct torque for each connection. This helps ensure safe and compliant performance.
FuseBox F3024M – 24 Way (Double Bank)
Need even more capacity?
See the FuseBox F3032M 32 Way or the powerful FuseBox F3048M 48 Way triple bank consumer unit.
Summary – FuseBox F3024M Double Row Consumer Unit
The F3024M is a 24-way dual-row consumer unit for large installs. Built for flexibility and safety, it’s ideal for homes and light commercial projects needing more circuits without SPD.
