Description
High-Output Ceiling Sounder for MAGDUO Fire Alarm Systems
ESP MAGDUOSW 2 Wire Ceiling Sounder – Red
The ESP MAGDUOSW is a red ceiling-mounted 2-wire sounder designed for use with the MAGDUO2, MAGDUO4, and MAGDUO8 fire alarm panels. It delivers a strong 90+ dB audible alert and is ideal for providing clear fire signalling in open-plan areas, corridors, stairwells, and communal spaces.
This conventional sounder is fully certified to BS EN 54-3, features low power consumption, and supports a wide voltage range from both mains and battery-powered control panels. Its durable construction and compact ceiling-mount design ensure a reliable and discreet fire alarm installation.
Key Features – ESP MAGDUOSW 2 Wire Ceiling Sounder
- Red ceiling sounder for ESP MAGDUO panels
- High sound output: 90+ dB at 1 metre
- Compatible with 2-wire MAGDUO systems (2, 4, and 8 zone)
- Low current consumption: 10 mA (alarm) / 0.92 mA (quiescent)
- Supports up to 36 Device Loading Units (DLUs)
- Fully certified to BS EN 54-3
- 3-year manufacturer warranty
Technical Overview – ESP MAGDUOSW 2 Wire Sounder
- Dimensions: Ø105mm x 72mm
- Operating Voltage (Mains Panel): 25.5 – 35V DC
- Operating Voltage (Battery Panel): 21 – 26V DC
- Quiescent Current: 0.92 mA
- Alarm Current: 10 mA
- DLU Rating: 36
- Wiring Type: 2-Wire Conventional
- Max Cable Size: 1.5mm²
- Ingress Protection: IP21C
- Operating Temperature: -10°C to +50°C
- Compliance: BS EN 54-3
What’s Included
- 1 x ESP MAGDUOSW Red Ceiling Sounder
- Mounting accessories
- Installation guide
✅ Why Choose This Product?
The MAGDUOSW ceiling sounder provides loud, reliable audible alerts for MAGDUO fire alarm systems. With its high output and low current draw, it’s ideal for areas where clear sound is critical for safety. Simple installation and BS EN 54-3 compliance make it a trusted choice for professional installers.
️ Guarantee & Compliance
Supplied with a 3-year manufacturer warranty, this product complies with BS EN 54-3, ensuring suitability for UK-regulated fire alarm installations.
