Description
PowerSure 5 Core 1.5mm² NYY-J Cable – 100m
Doncaster Cables NYY5C1.5/100
Durable, UV-Stabilised Cable for Fixed Wiring Applications
The Doncaster Cables PowerSure NYY-J Cable is a high-quality solution for power and control in fixed wiring installations. Designed to BS EN 60502-1 standards, this cable delivers reliable performance for both indoor and outdoor applications. Its UV-stabilised black PVC sheath ensures resilience against sunlight and environmental factors, making it ideal for a range of installations.
Key Features of PowerSure 5 Core 1.5mm² NYY-J Cable
- Conductor: Plain annealed copper, compliant with BS EN 60228.
- Insulation: High-grade PVC insulation for enhanced durability.
- Outer Sheath: UV-stabilised black PVC sheath for outdoor resilience.
- Voltage Rating: 600/1000V, suitable for various applications.
- Operating Temperatures:
- Minimum: -15°C.
- Maximum: 70°C.
- Bending Radius: Minimum 12 times the cable’s outer diameter for flexible installation.
- Core Colours:
- 2 Core: Brown, Blue.
- 3 Core: Brown, Blue, Green/Yellow.
- 4 Core: Brown, Green/Yellow, Black, Grey.
- 5 Core: Brown, Blue, Green/Yellow, Black, Grey.
- Current Ratings: Refer to tables 4D2A and 4D2B in the BS7671 IET Wiring Regulations.
Product Details
NYY5C1.5 (5 Core, 1.5mm²)
- Nominal Insulation Thickness: 0.8mm.
- Nominal Sheath Thickness: 1.8mm.
- Approximate Overall Diameter: 12.6mm.
- Conductor Class: Class 1 (solid).
Additional configurations and sizes are available upon request. Contact us for more details about the NYY-J range.
Important Note:
This chart and data are for guidance purposes only. Always consider the actual dimensions of the cables and glands before making a final selection. Manufacturing tolerances as per BS6121: Part 1: 1989 should be taken into account to ensure the correct fit and functionality.
Why Choose Doncaster Cables?
Doncaster Cables is renowned for manufacturing the highest quality cables, trusted by professionals for their durability and adherence to industry standards.
Electrical4Less is an authorised distributor of Doncaster Cables, offering a comprehensive range of PowerSure products to meet your needs.
Why Choose the PowerSure NYY-J Cable?
- Durable Construction: UV-stabilised sheath ensures reliable performance in outdoor and harsh conditions.
- Versatile Applications: Suitable for fixed wiring installations with minimal mechanical stress.
- Compliance: Fully certified to BS EN 60502-1 and BS7671 standards for safe and effective use.
FAQs
- Q: Is this cable suitable for outdoor use?
A: Yes, the UV-stabilised black sheath makes it ideal for outdoor environments, including direct sunlight exposure. - Q: What is the minimum bending radius for this cable?
A: The cable requires a bending radius of at least 12 times its overall diameter.
