Description
PowerSure 4 Core 1.5mm² NYY-J Cable – 100m
Doncaster Cables NYY4C1.5/100
Durable, UV-Stabilised Cable for Fixed Wiring
The Doncaster Cables PowerSure NYY-J Cable is an excellent choice for power and control in fixed wiring installations. Built to BS EN 60502-1 standards, this cable provides reliable performance for both indoor and outdoor applications. Its UV-stabilised black PVC sheath ensures protection from sunlight and environmental factors, making it ideal for a wide range of installations.
Key Features of PowerSure 4 Core 1.5mm² NYY-J Cable
- Conductor: Plain annealed copper, compliant with BS EN 60228.
- Insulation: High-quality PVC insulation for long-term durability.
- Outer Sheath: UV-stabilised black PVC sheath for outdoor resilience.
- Voltage Rating: 600/1000V for versatile applications.
- Operating Temperatures:
- Minimum: -15°C.
- Maximum: 70°C.
- Bending Radius: Minimum 12 times the cable’s outer diameter for safe and efficient installation.
- Core Colours:
- 2 Core: Brown, Blue.
- 3 Core: Brown, Blue, Green/Yellow.
- 4 Core: Brown, Green/Yellow, Black, Grey.
- 5 Core: Brown, Blue, Green/Yellow, Black, Grey.
- Current Ratings: Refer to tables 4D2A and 4D2B in the BS7671 IET Wiring Regulations.
Product Details
NYY4C1.5 (4 Core, 1.5mm²)
- Nominal Insulation Thickness: 0.8mm.
- Nominal Sheath Thickness: 1.8mm.
- Approximate Overall Diameter: 12.0mm.
- Conductor Class: Class 1 (solid).
Additional configurations and sizes are available upon request. Contact us for more information about the NYY-J range.
Important Note:
This chart and data are for guidance purposes only. Always consider the actual dimensions of the cables and glands before making a final selection. Manufacturing tolerances as per BS6121: Part 1: 1989 should be taken into account to ensure the correct fit and functionality.
Why Choose Doncaster Cables?
Doncaster Cables is a trusted name in the industry, known for producing the highest quality cables. Their products meet stringent manufacturing standards, ensuring reliable performance and long-lasting durability for any project.
Electrical4Less is an authorised distributor of Doncaster Cables, offering a full range of PowerSure products to suit your needs.
Why Choose the PowerSure NYY-J Cable?
- Durable Construction: UV-stabilised sheath ensures outdoor resilience and protection against harsh conditions.
- Versatile Applications: Suitable for fixed wiring installations with minimal mechanical stress.
- Compliance: Fully certified to BS EN 60502-1 and BS7671 standards for safe and effective use.
FAQs
- Q: Can this cable be used in outdoor installations?
A: Yes, the UV-stabilised black sheath ensures excellent protection for outdoor use. - Q: What is the minimum bending radius for this cable?
A: The minimum bending radius is 12 times the cable’s overall diameter.
