Description
Heavy-Duty TPN Switch Fuse for Industrial Isolation
Axiom SF100N 100A 415V TPN Switch Fuse
Control and isolate three-phase circuits confidently with the Axiom SF100N 100A 415V TPN Switch Fuse. Designed for industrial and commercial settings, this wall-mounted switchfuse isolator combines a robust enclosure with a lockable rotary handle for safe manual disconnection during servicing, inspection, and maintenance.
Built for reliable protection, the SF100N accepts BS88 Part 2 fuses and delivers a strong breaking capacity of 80kA. Its fully isolated top and bottom fuse arrangement supports safer fuse replacement, while the IP54 enclosure helps protect against dust and splashing water in demanding working environments.
With a 100A current rating, 415V supply, TPN pole configuration, and overall size of 325 x 400 x 220mm, the SF100N is a dependable choice for installers who need durable three-phase isolation with straightforward wall mounting.
Key Features – Axiom SF100N 100A 415V TPN Switch Fuse
- 100A switch fuse for 415V three-phase applications
- TPN configuration for dependable industrial isolation
- Lockable rotary handle for safer circuit deactivation during maintenance
- Uses BS88 Part 2 fuses with fully isolated top and bottom fuse arrangement
- 80kA breaking capacity for demanding installations
Technical Overview – Axiom SF100N 100A 415V TPN Switch Fuse
- Product type: Switchfuse isolator
- Current rating: 100A
- Voltage: 415V
- Number of poles: TPN
- Phase: 3
- Frequency: 50/60Hz
- Ingress protection: IP54
- Breaking capacity: 80kA
- Mounting: Wall
- Terminal capacity: 35mm²
- Torque: 2.5N-m
- Knockouts: 3 total | 25mm, 32mm, 40mm
- Dimensions: 325 x 400 x 220mm
- Body material: Enclosure – CRCA | Switch body – DMC
- Approvals: CE, UKCA
- Warranty: 1 year
Why Choose This Product?
Choose the Axiom SF100N when you need a durable 100A 415V TPN switch fuse for safe three-phase isolation. Its lockable handle, high fault capacity, and fully isolated fuse layout make it a strong option for professional industrial and commercial installations.
About Axiom
Axiom supplies practical electrical products for commercial and industrial installations, focusing on reliable protection, straightforward installation, and compliance with recognised standards.
Guarantee & Compliance
The Axiom SF100N is CE and UKCA approved, complies with the low voltage directive, and is designed to take BS88 Part 2 fuses. Install in line with current wiring regulations and manufacturer instructions.
