ALL LED Seamless RGB 5W/m 24V IP67 COB Dotless LED Strip – 30m Reel

Description

🌈 Vibrant Waterproof RGB Strip Lighting – 30m IP67 COB Reel

Enhance outdoor and wet-area lighting with the RGB COB 24V IP67 LED STRIP – 30M. This high-performance LED strip features 840 LEDs/m in a seamless COB layout, delivering smooth RGB colour transitions with no visible dots. Housed in a robust IP67 waterproof casing, it’s ideal for exterior signage, garden lighting, and damp interior zones like kitchens or bathrooms.

At just 5W per metre, this tape offers an energy-efficient solution for dynamic colour effects while maintaining vibrant output. With cut points every 50mm and a 30m continuous reel, it gives designers excellent flexibility with minimal joins – essential for uninterrupted visual flow.

🔧 Key Features – RGB COB 24V IP67 Waterproof LED Strip

• ✅ Seamless COB Lighting – 840 LEDs/m for dot-free brilliance
• ✅ RGB Output – Vibrant colour mixing with up to 190lm
• ✅ Weatherproof IP67 – Perfect for outdoor and wet-zone installs
• ✅ Cuttable – Every 50mm for layout precision
• ✅ Energy-Efficient – 5W/m power draw with long lifespan
• ✅ Slim & Durable – 10mm width in silicone-coated waterproof body
• ✅ Long Life – 30,000 hours rated performance
• ✅ Trusted Brand – 3-year warranty from All LED

⚙️ Technical Specifications – IP67 RGB COB Dotless LED Strip

Electrical & Optical

• Voltage: 24V DC
• Wattage: 5W per metre
• Luminous Output: RED ≤37lm, GREEN ≤129lm, BLUE ≤21lm, RGB ≤190lm
• Beam Angle: 120°
• CRI: >80
• SDCM: <6
• Peak Intensity: RGB ≤47cd

Physical

• IP Rating: IP67 (Dustproof & water-resistant)
• Length: 30m reel
• Cut Points: Every 50mm
• LED Density: 840 LEDs/m
• PCB Width: 10mm
• Operating Temp: -20°C to +40°C
• Class: III
• Lifespan: 30,000 hours (L70 B50)
• Switching Cycles: >15,000
• Warranty: 3 years

📢 Installation Advice

For best results, install this IP67 RGB COB Dotless LED Strip in compatible aluminium profiles to ensure heat management and mechanical protection. Secure with outdoor-grade fixings or clips depending on the environment.

🔗 Browse 👉 LED Strip Profiles

🔌 Driver & Controller Guidance

💡 This 30m IP67 RGB COB Dotless LED Strip should not be powered as one continuous run.

• Max length for single-ended feed: 10 metres
• Max length for double-ended feed: 20 metres

Choose a driver sized by: Length × 5W + 20%. Use compatible RGB controllers for full colour control 👉 ALL LED Strip Lights Controllers

Example: For 6m → 6 × 5W = 30W + 20% ≈ 36W driver recommended.

💬 Why Choose This RGB IP67 LED Strip?

• ✅ Fully waterproof RGB COB design
• ✅ Clean, dot-free lighting with excellent flexibility
• ✅ Easy to cut and shape around exterior features
• ✅ Long 30m reel reduces joins
• ✅ Made for professional outdoor installations
