Essential for any major upgrade, renovation or new build. The Screwless Socket and 2G Modular Combination Plate allows for a power, fast charge USB and bespoke signal distribution solution to be combined in one area.
Compatible with our extensive range of modular inserts this plate can be configured to suit your requirements, be it Satellite TV, DAB, Telecoms, oe networking.
2G Socket on the left and 2G modular on the right.
Knightsbridge FASTCHARGE USB sockets can deliver a 0-50% charge in under 30 minutes with compatible devices.
FASTCHARGE is achieved by the intelligent switching of voltages between 5V to up to 12V to optimize and deliver the maximum input your device can handle. Your device decides how much power it’s going to draw down.
Devices that support QC3.0 (many Android based devices) can use the USB-A port to achieve up to 18W. Devices that support USB-PD (many Android based devices and iPhone8 or above) can use the USB-C port to achieve up to 18W. If a legacy device does not support these then up to 10W can be achieved from the USB-A port, or up to 15W from the USB-C port
- Double pole switches provide additional safety
- Twin earthing points for high integrity earthing requirements
- Space for up to 2 x Euro module inserts (25x50mm)
- Constructed from high quality components and materials to ensure the longevity of the install
- Fully certified to the latest British Safety Standards
- Over Voltage Category III – suitable for domestic and commercial installations
- Built in overheat and overload protection
- ErP Ready (0.1W in stand-by mode)
IMPORTANT: The device controls the power being drawn, not the socket. Most compatible devices will only activate fastcharge between 0-70% battery power. After this it will revert to standard charging parameters to protect battery
|CONSTRUCTION||Premium grade steel|
|PRIMARY VOLTAGE||230V 50Hz|
|RECESSED DEPTH||22.2 mm|
|MIN. MOUNTING BOX DEPTH||35mm|
